万字长文深度解析JDK序列化原理及Fury高度兼容的极致性能实现

    private void writeObject(java.io.ObjectOutputStream s)
        throws java.io.IOException {


        java.io.ObjectOutputStream.PutField fields = s.putFields();
        fields.put("rnd", U.getLong(Thread.currentThread(), SEED));
        fields.put("initialized", true);
        s.writeFields();
    }

需要注意defaultWriteObject写的数据可能会通过readFields进行读取，因此其格式需要和和putFields兼容。另外在自定义序列化时defaultWriteObject/putFields两者只能调用一个。

public static class CustomReplaceClass implements Serializable {
  Object writeReplace() {
    return new CustomReplaceClass();
  }


  Object readResolve() {
    return new CustomReplaceClass();
  }
}
Exception in thread "main" java.lang.StackOverflowError
  at java.base/java.lang.reflect.InvocationTargetException.<init>(InvocationTargetException.java:73)
  at jdk.internal.reflect.GeneratedMethodAccessor1.invoke(Unknown Source)
  at java.base/jdk.internal.reflect.DelegatingMethodAccessorImpl.invoke(DelegatingMethodAccessorImpl.java:43)
  at java.base/java.lang.reflect.Method.invoke(Method.java:566)
  at com.caucho.hessian.io.WriteReplaceSerializer.writeReplace(WriteReplaceSerializer.java:184)
  at com.caucho.hessian.io.WriteReplaceSerializer.writeObject(WriteReplaceSerializer.java:155)
  at com.caucho.hessian.io.Hessian2Output.writeObject(Hessian2Output.java:465)
  at com.caucho.hessian.io.WriteReplaceSerializer.writeObject(WriteReplaceSerializer.java:167)
  at com.caucho.hessian.io.Hessian2Output.writeObject(Hessian2Output.java:465)
  at com.caucho.hessian.io.WriteReplaceSerializer.writeObject(WriteReplaceSerializer.java:167)
  at com.caucho.hessian.io.Hessian2Output.writeObject(Hessian2Output.java:465)
  at com.caucho.hessian.io.WriteReplaceSerializer.writeObject(WriteReplaceSerializer.java:167)
  at com.caucho.hessian.io.Hessian2Output.writeObject(Hessian2Output.java:465)

    /**
     * Head of linked list.
     * Invariant: head.item == null
     */
    transient Node<E> head;


    /**
     * Tail of linked list.
     * Invariant: last.next == null
     */
    private transient Node<E> last;


    private void writeObject(java.io.ObjectOutputStream s)
        throws java.io.IOException {


        fullyLock();
        try {
            // Write out any hidden stuff, plus capacity
            s.defaultWriteObject();


            // Write out all elements in the proper order.
            for (Node<E> p = head.next; p != null; p = p.next)
                s.writeObject(p.item);


            // Use trailing null as sentinel
            s.writeObject(null);
        } finally {
            fullyUnlock();
        }
    }

private void readObject(java.io.ObjectInputStream s)
    throws java.io.IOException, ClassNotFoundException {
    s.defaultReadObject();
    readHolds = new ThreadLocalHoldCounter();
    setState(0); // reset to unlocked state
}

• JDK序列化性能很差，导致kryo序列化性能大幅退化

• JDK序列化结果很大，导致kryo序列化数据膨胀

• 转发给JDK序列化的对象子图不会跟Kryo share同一个引用表，如果该子图共享/循环引用了其它对象，则会出现重复序列化/递归栈溢出

kryo不支持父子类出现重名字段，这在某些条件下也会成为一个使用限制。

• Jsonb不支持任何JDK自定义序列化方法，反序列化会报错

• Fst不支持类型前后兼容，无法在服务化场景使用

整体实现在：

io.fury.serializers.ReplaceResolveSerializer和

io.fury.serializers.ObjectStreamSerializer

ReplaceResolveSerializer

ObjectStreamSerializer

ObjectStreamSerializer实现了整套：

JDK writeObject/readObject/readObjectNoData/registerValidation

行为，保证行为跟JDK的一致性，在任意情况下序列化都不会报错。

由于用户在：

writeObject/readObject/ readObjectNoData/registerValidation

里面调用的是：

JDK ObjectOutputStream/ObjectInputStream PutField/GetField的接口

因此Fury也实现了一套：

ObjectOutputStream/ObjectInputStream/PutField/ GetField

的子类，保证实际序列化逻辑可以转发给Fury。

为了保证类型前后兼容，同时保证：

defaultWriteObject/defaultReadObject

创建JITCompatibleSerializer进行序列化。

序列化器初始化部分

• 获取无参数构造函数或者第一个Non Serializable父类无参数构造函数。为了避免JDK17以上版本的反射访问权限问题，在JDK17以上版本会通过Unsafe直接获取ObjectStreamClass.lookup(type)抽取的构造函数。

    Constructor constructor;
    try {
      constructor = type.getConstructor();
      if (!constructor.isAccessible()) {
        constructor.setAccessible(true);
      }
    } catch (Exception e) {
      constructor =
          (Constructor) ReflectionUtils.getObjectFieldValue(ObjectStreamClass.lookup(type), "cons");
    }

• 遍历对象层次结构，创建每个class的JITCompatibleSerializer/CompatibleSerializer/ FuryObjectOutputStream/FuryObjectInputStream等。其中slotsSerializer是JITCompatibleSerializer，用于执行ObjectOutputStream#defaultWriteObject/ObjectInputStream#defaultReadObject。compatibleStreamSerializer用于序列化将PutFields设置的字段，因为PutFields设置的字段可能在当前对象类型里面不存在，因此这种情况下无法使用JIT进行类型推断和序列化。

    List<SlotsInfo> slotsInfoList = new ArrayList<>();
    Class<?> end = type;
    // locate closest non-serializable superclass
    while (end != null && Serializable.class.isAssignableFrom(end)) {
      end = end.getSuperclass();
    }
    while (type != end) {
      slotsInfoList.add(new SlotsInfo(fury, type));
      type = type.getSuperclass();
    }
    Collections.reverse(slotsInfoList);
    slotsInfos = slotsInfoList.toArray(new SlotsInfo[0]);

  private static class SlotsInfo {
    private final Class<?> cls;
    private final Method writeObjectMethod;
    private final Method readObjectMethod;
    private final Method readObjectNoData;
    private final CompatibleSerializerBase slotsSerializer;
    private final ObjectIntMap<String> fieldIndexMap;
    private final FieldResolver putFieldsResolver;
    private final CompatibleSerializer compatibleStreamSerializer;
    private final FuryObjectOutputStream objectOutputStream;
    private final FuryObjectInputStream objectInputStream;
    private final ObjectArray getFieldPool;
  }

序列化器执行部分

• 序列化执行部分

• 写入所有Serializable class数量

• 遍历对象类层次结构，依次序列化每个类型的字段数据。序列化每个类型的数据分为以下几个部分：

• 如果当前对象所在类型没有定义writeObject方法，则直接调用slotsSerializer (JITCompatibleSerializer)序列化当前类型所有字段。

• 如果前对象所在类型定义了writeObject方法，则会缓存之前一次序列化的上下文，然后调用writeObject方法，传入Fury实现的FuryObjectOutputStream。

• 在FuryObjectOutputStream里面，同时也会针对putFields/writeFields/defaultWriteObject进行特殊的处理。putFields/writeFields会把对象转换成CompatibleSerializer可识别的array形式，defaultWriteObject则会直接调用slotsSerializer (JITCompatibleSerializer)序列化当前类型所有字段。

for (SlotsInfo slotsInfo : slotsInfos) {
    buffer.writeShort((short) slotsInfos.length);
    classResolver.writeClassInternal(buffer, slotsInfo.cls);
    Method writeObjectMethod = slotsInfo.writeObjectMethod;
    if (writeObjectMethod == null) {
      slotsInfo.slotsSerializer.write(buffer, value);
    } else {
      FuryObjectOutputStream objectOutputStream = slotsInfo.objectOutputStream;
      Object oldObject = objectOutputStream.targetObject;
      MemoryBuffer oldBuffer = objectOutputStream.buffer;
      FuryObjectOutputStream.PutFieldImpl oldPutField = objectOutputStream.curPut;
      boolean fieldsWritten = objectOutputStream.fieldsWritten;
      try {
        objectOutputStream.targetObject = value;
        objectOutputStream.buffer = buffer;
        objectOutputStream.curPut = null;
        objectOutputStream.fieldsWritten = false;
        writeObjectMethod.invoke(value, objectOutputStream);
      } finally {
        objectOutputStream.targetObject = oldObject;
        objectOutputStream.buffer = oldBuffer;
        objectOutputStream.curPut = oldPutField;
        objectOutputStream.fieldsWritten = fieldsWritten;
      }
    }
  }

• 根据构造函数创建对象实例。

• 将对象实例写入引用表。

• 读取对象层次结构所有Serializable Class数量。

• 依次从数据读取class，并和当前类型层次结构的class进行比较。如果不一致，则代表当前类型层次结构发生了变化，引入了新的父类，如果该类型定义了readObjectNoData，则调用该方法进行初始化，然后向上遍历类型层次结构，直到找到相同类型。

• 反序列化该类型的所有字段值并设置到对象字段上面。

• 如果对象没有定义readObject方法，则直接调用slotsSerializer (JITCompatibleSerializer)进行反序列化。

• 如果定义了readObject方法，则调用对象的readObject方法，传入Fury实现的FuryObjectInputStream。

• 在FuryObjectInputStream里面，同时也会针对readFields/defaultReadObject进行特殊的处理。readFields会使用CompatibleSerializer把对象转换成可识别的GetField形式，defaultReadObject则会直接调用slotsSerializer (JITCompatibleSerializer)反序列化当前类型所有字段。

• 如果在readObject期间用户通过registerValidation注册了ObjectInputValidation回调，则会在返回该对象之前，按照优先级依次执行回调。

• 至此反序列化完成。核心代码大致如下：

    Object obj = null;
    if (constructor != null) {
      try {
        obj = constructor.newInstance();
      } catch (InstantiationException | IllegalAccessException | InvocationTargetException e) {
        Platform.throwException(e);
      }
    } else {
      obj = Platform.newInstance(type);
    }
    fury.getReferenceResolver().reference(obj);
    int numClasses = buffer.readShort();
    int slotIndex = 0;
    TreeMap<Integer, ObjectInputValidation> callbacks = new TreeMap<>(Collections.reverseOrder());
    for (int i = 0; i < numClasses; i++) {
      Class<?> currentClass = classResolver.readClassInternal(buffer);
      SlotsInfo slotsInfo = slotsInfos[slotIndex++];
      while (currentClass != slotsInfo.cls) {
        // the receiver's version extends classes that are not extended by the sender's version.
        Method readObjectNoData = slotsInfo.readObjectNoData;
        if (readObjectNoData != null) {
          readObjectNoData.invoke(obj);
        }
        slotsInfo = slotsInfos[slotIndex++];
      }
      Method readObjectMethod = slotsInfo.readObjectMethod;
      if (readObjectMethod == null) {
        slotsInfo.slotsSerializer.readAndSetFields(buffer, obj);
      } else {
        FuryObjectInputStream objectInputStream = slotsInfo.objectInputStream;
        MemoryBuffer oldBuffer = objectInputStream.buffer;
        Object oldObject = objectInputStream.targetObject;
        FuryObjectInputStream.GetFieldImpl oldGetField = objectInputStream.getField;
        FuryObjectInputStream.GetFieldImpl getField =
            (FuryObjectInputStream.GetFieldImpl) slotsInfo.getFieldPool.popOrNull();
        if (getField == null) {
          getField = new FuryObjectInputStream.GetFieldImpl(slotsInfo);
        }
        boolean fieldsRead = objectInputStream.fieldsRead;
        try {
          objectInputStream.fieldsRead = false;
          objectInputStream.buffer = buffer;
          objectInputStream.targetObject = obj;
          objectInputStream.getField = getField;
          objectInputStream.callbacks = callbacks;
          readObjectMethod.invoke(obj, objectInputStream);
        } finally {
          objectInputStream.fieldsRead = fieldsRead;
          objectInputStream.buffer = oldBuffer;
          objectInputStream.targetObject = oldObject;
          objectInputStream.getField = oldGetField;
          slotsInfo.getFieldPool.add(getField);
          objectInputStream.callbacks = null;
          Arrays.fill(getField.vals, FuryObjectInputStream.NO_VALUE_STUB);
        }
      }
    }
    for (ObjectInputValidation validation : callbacks.values()) {
      validation.validateObject();
    }

[1]writeObject：https://docs.oracle.com/en/java/javase/18/docs/specs/serialization/output.html#the-writeobject-method

[2]readObject：

https://docs.oracle.com/en/java/javase/18/docs/specs/serialization/input.html#the-readobject-method

[3]writeReplace：

https://docs.oracle.com/en/java/javase/18/docs/specs/serialization/output.html#the-writereplace-method

[4]readResolve：https://docs.oracle.com/en/java/javase/18/docs/specs/serialization/input.html#the-readresolve-method
